Pelco VideoXpert Pro serveris Eco 3
- Stock: Teirautis
Pranešti kai prekė bus prekyboje!
Pelco VideoXpert® Professional Eco 3 vaizdo įrašų saugojimo serveris.
Techninės specifikacijos:
| Objektas | Eco 3 Server |
| Form Factor | Rack (1U) |
| Processor | Intel Core i5-9500 |
| Memory | 16 GB DDR4 |
| Operating System | Microsoft Windows 10 IoT Enterprise64-bit (LTSC) |
| OS Drive | M.2 NVMe 256 GB |
| Storage | |
| Max* | 32 TB (7200 RPM SATA) |
| RAID Level** | JBOD |
| Dell iDRAC Controller | N/A |
| USB Ports | |
| USB 2.0 | N/A |
| USB 3.0 | 2x front |
| USB 3.1 Type-C | 1x front, 2x rear |
| Video | |
| Video Outputs | 4x Mini DisplayPort (DP++) 1.4 |
| Video system | NVIDIA Quadro P620 (2 GB memory) |
| Maximum Video Resolution | mDP 1.4 direct connect, HDR 5120 x 2880 at 60 Hz (30-bit color) |
| Audio | |
| Outputs | DisplayPort Audio |
| Connector Types | mDP Cable (out) |
| Networking | |
| Gigabit Ethernet (1000Base-T) ports | 1x 1 Gigabit Ethernet (1000 Base-T), 1x10 Gigabit Ethernet (10 G Base-T) |
| Recording Throughput | Up to 250 Mbps |
| IP version | IPv4 and IPv6 |
| Power | |
| Input | 100 to 240 VAC 50/60 Hz, autoranging |
| Supply | Internal 550 W—1 included, 2 maximum. Note: This system is also designed to be connected to IT power systems with a phase-to-phase voltage not exceeding 230 V. |
| Consumption | 2107 BTU/hr max (550 W power supply) Note: Heat dissipation is calculated by using the power supply maximum wattage rating. Results will vary depending on system load. |
| Environmental | |
| Operating Temperature | 10° to 35°C at unit front air intake Note: Maximum temperature is reduced by 1°C/300 m above 50 m |
| Non-Operating Temperature | –40° to 65°C |
| Operating Relative Humidity | 10% to 85%, non-condensing |
| Non-Operating Relative Humidity | 10% to 90%, non-condensing |
| Operating Altitude | Maximum of 3048 m |
| Operating Vibration | 0.26 Grms |
| Physical | |
| Dimensions (D x W x H) | 57.75 x 48.2 x 4.28 cm |
| Rack Mounting | 1 RU |
| Maximum Weight2 | 12.42 kg |
* You must have a separate Workstation with the Power 2 series Server.
** Maximum storage based on JBOD configuration
Gamintojas
JAV vaizdo sistemų gamintojas, užtikrinantis vakarietiškus standartus, kokybę, patikimumą.
Pelco yra pasaulinis lyderis, jau virš 63 metų kuriantis, plėtojantis ir gaminantis vaizdo stebėjimo sistemų sprendimus, įskaitant vaizdo stebėjimo kameras, vaizdo valdymo ir įrašymo sistemas, apsauginę programinę įrangą ir teikiantis susijusias paslaugas.
Pelco puikiai žinomas visame pasaulyje kaip visapusiškas vaizdo technologijų tiekėjas, užtikrinantis spartų diegimą, aukštesnį sistemos atsparumo lygį.
Pelco priklauso Motorola grupei.
