Valdoma spec tarnybų ir paskirties kamera, GPS, SIM, 4G, Baterija

Camera

Image Sensor

1/1.8" CMOS

Pixel

2 MP

Max. Resolution

1920 (H) × 1080 (V)

ROM

4 GB

RAM

1 GB

Electronic Shutter Speed

1s–1/30,000s

Scanning System

Progressive

Min. Illumination

0.001 lux@F1.6 (Color, 30 IRE);
0.0001 lux@F1.6 (B/W, 30 IRE);
0 lux (illuminator on)

Illumination Distance

100 m (328.08 ft) (IR)

Illuminator On/Off Control

Zoom Prio; Manual; Auto; Off

Illuminator Number

3 (IR light)

Lens

Focal Length

6 mm–186 mm

Max. Aperture

F1.6–F4.0

Field of View

H: 59.8°–2.8°; V: 33.7°–1.9°; D: 63.3°–4°

Optical Zoom

31 ×

Focus Control

Auto; Semi-Auto; Manual

Iris Control

Auto; Manual

DORI Distance

Detect

Observe

Recognize

Identify

2565.5 m (8416.99 ft)

1013.4 m (3324.80 ft)

513.3 m

(1684.06 ft)

256.6 m

(841.86 ft)

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless;
Tilt: -90 ° to +30°

Manual Control Speed

Pan: 0.1°/S–120°/s;
Tilt: 0.1°/S–70°/s

Preset Speed

Pan: 0.1°/S–169°/s
Tilt: 0.1°/S–160°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Pattern; Preset; Scan; Tour

PTZ Protocol

DH-SD
Pelco-P/D (Auto recognition)

Intelligence

Video Metadata

Supports detection of motor vehicles, non-motor vehicles, faces and human bodies, optimization, capturing pictures, and uploading high-quality face snapshots. It extracts attributes from motor vehicles, detecting up to 10 attributes for them.

IVS (Perimeter Protection)

Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking

Face Detection

Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots.

Construction Monitoring

Detects 6 helmet colors: Red, orange, yellow, blue, white, and black. An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that they are wearing does not match the configured color. It also supports compliance detection for work uniforms. Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images (the images must be 1080p and in the JPG format). An alarm will be triggered when the similarity between the detected work uniform and the samples in the library is below the set threshold (that is, below the minimum compliance standard for work uniforms). The system supports detecting the attributes of work uniforms such as the color of the uniform, and whether or not the person is wearing a mask and wearing shoe covers. An alarm will be triggered when the target is detected as not meeting the set requirements. It also detects and triggers alarms when only one person is in the construction site, and when no one is present in the detection area such as when a worker leaves their post or an area is left unmanned.

Auto Tracking

Yes

SMD

SMD4.0

Quick Pick

Yes

Active Deterrence

Sound Warning

Offers 27 types of sound alarms, and supports importing custom sound alarms. The sound level is high, medium and low, and the alarm duration is 5 s–30 s.

Video

Video Compression

H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Video Frame Rate

Main stream: 1080p/1.3M/720p @(1-25/30 fps)
Sub stream 1: D1/CIF@ (1-25/30 fps)
Sub stream 2: 1080p/1.3M/720p/CIF @(1-25/30 fps)

Bit Rate Control

CBR/VBR

Video Bit Rate

H264: 64 Kbps–10,496 Kbps
H265: 25 Kbps–6,400 Kbps

Day/Night

Auto (ICR)

BLC

Yes

WDR

140 dB

HLC

Yes

White Balance

Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Electronic (EIS)

Defog

Electronic

Digital Zoom

16 ×

Image Rotation

180°

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view;
Multiple colors available

S/N Ratio

≥55 dB

Audio

Audio Compression

PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723

Network

Network Port

RJ-45 (10/100 Base-T)

Wi-Fi

Yes

Wi-Fi Standard

IEEE802.11a; IEEE802.11b; IEEE802.11g; IEEE802.11ac; IEEE802.11n

Wi-Fi Frequency Range

2.4 GHz;5 GHz

Wi-Fi Transmission Rate

433.3 Mbps

Carrier Network System

LTE-FDD/LTE-TDD/WCDMA/GSM

Wireless Carrier Frequency Band

LTE-TDD: Tri-band Band 38/40/41
LTE-FDD: Hepta-band Band 1/3/5/7/8/20/28
WCDMA: Tri-band Band 1/5/8
GSM: Tri-band 850/900/1800

Network Protocol

FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP

Interoperability

ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

Micro SD card (512 GB); FTP/SFTP; NAS

Browser

IE 9 and later versions;
Chrome 41 and later versions;
Firefox 52 and later versions;
Safari 10 and later versions

Management Software

DMSS; DSS Pro

Mobile Client

iOS; Android

Port

RS-485

1 (baud rate: 1200 bps–9600 bps)

Audio Input

1 channel (LINE IN, bare wire,built-in mic (mutually exclusive))

Audio Output

1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive))

Alarm Input

1 (on-off value input: 0–5 VDC)

Alarm Output

1 channel

Alarm Linkage

Capture; recording; send email; preset; tour; pattern; alarm digital output; audio

Alarm Event

Motion/tampering detection; network disconnection detection; IP conflict detection; audio detection; memory card state detection; memory space detection

Power

Power Supply

12 VDC, 5 A ± 10% (included)

Power Output

5 V, 1 A

Battery Life on a Full Charge

10 h, The PTZ is set to not move by default, videos can be stored on the SD card,
and Bluetooth, Wi-Fi, AP, Mic, speaker and SIM1/2 are disabled by default.

Power Consumption

Basic: 8 W;
Max: 38 W (illuminator + PTZ + battery)

Environment

Operating Temperature

–20 °C to +55 °C (–4 °F to +131 °F)

Operating Humidity

≤95%

Protection

TVS 6000 V lightning proof; IP66; surge protection; voltage transient protection

Structure

Casing Material

Aluminum alloy ADC12, magnesium alloy AZ91D

Product Dimensions

Φ160 mm × 265 mm (bare machine) 480 mm × 350 mm × 220 mm (L × W × H) (aluminum trolley case)

Net Weight

3.8 kg (8.38 lb)

Gross Weight

12.5 kg (27.56 lb)
