Dahua UTP 4 prievadų, 4 PoE komutatorius, 1 Uplink

Technical Specification

Model

DH-PFS3005-4ET-60

Ethernet Port

1*10/100 Base-T

4*10/100 Base-T (PoE power supply)

PoE Power Consumption

Port1≤60W, Port2-4≤30W, Total≤60W

PoE PIN Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

PoE Power Management

Support

PoE Protocol

IEEE802.3af (PoE), IEEE802.3at (PoE+), Hi-PoE

Switching Capacity

1Gbps

Packet Forwarding Rate

744Kpps

Packet Buffer Memory

448Kb

MAC Table Size

1K

Flow Control

Enable

Application Humidity

5%~95%

Power

DC48~57V power adapter

Lightning Protection

Common Mode 2KV

Differential Mode 1KV

ESD Protection

Air Discharge 8KV

Contact Discharge 6KV

Working Temperature

-10°C~55°C

Weight

290g

Dimension(W×D×H)

130mm×85mm×26mm
